How to create ActionBar/Toolbar and Menu in Android Android22.07.2016
There are two kind of bar with control items in activity
Insert menu bar in your power apps screen. Select the menu bar. Using the drop-down option, select the custom property that you just created. In my case, it will be screen1.
ActionBar
is action control bar or navigation bar you usually see at the top of an app, it usually has an app logo icon on the left, name of the current screen next to the logo, and other menu list on the right. To use actionbar, you don’t have to define an actionbar in the layout file which is handy but it deosn’t give you much flexibilities when you want to do some customizations in the actionbar, such as adding background image, animations, place the actionbar on the bottom instead on the top.Toolbar
does evertying you can do with ActionBar, and gives you the freedom to do customiztions that you can’t do easily withActionBar
.
You can use either old ActionBar
(without any declarations in XML) or define android.support.v7.widget.Toolbar
in activity layout and customize it look and events (more coding in this way).
Build an App for your Pub or Bar in minutes. Select your template. The Pub/Bar template is pre-loaded with all the features you’ll need for your new app. Brand your Pub’s app. Just provide your Website and Facebook Page, and we’ll do the legwork for you pulling in info and branding. The menu bar is available in Mac apps built with Mac Catalyst. Where you override this method determines the menu system that the builder updates. To add and remove items from the menu bar using the main menu system, override build Menu(with:) in your app delegate. To build a context menu using the context system, override this method in your. If you build a PowerApp for mobile devices you are faced with limited space to display information. If you add a menu you will be loose additional space. This post shows how you can build a menu structure that uses a minimum of space. The minimum of space is used if the menu is not visible and uses a mimimum of space if it is visible. Electron - Menus. The desktop apps come with two types of menus – the application menu (on the top bar) and a context menu (right-click menu). We will learn how to create both of these in this chapter. We will be using two modules – the Menu and the MenuItem modules. Note that the Menu and the MenuItem modules are only available in the main.
ActionBar example
Let's look at ActionBar
and it's parameters. Insert following lines in onCreate
method and you'll get ActionBar
with icon
Toolbar example
ToolBar
was introduced in Android Lollipop, API 21 release and is the successor of the ActionBar
. It's a ViewGroup
that can be placed anywhere in your XML layouts. ToolBar
's appearance and behavior can be more easily customized than the ActionBar
.
There are two ways to use Toolbar
- Use a
Toolbar
as anActionBar
when you want to use the existingActionBar
facilities (such as menu inflation and selection, ActionBarDrawerToggle, and so on) but want to have more control over its appearance. - Use a standalone
Toolbar
when you want to use the pattern in your app for situations that anActionBar
would not support; for example, showing multiple toolbars on the screen, spanning only part of the width, and so on.
So, you should replace ActionBar
with ToolBar
if you want the flexibilities that comes with the Toolbar
(adding background image, animations, place the actionbar on the bottom instead on the top and so on). Note that the ActionBar
continues to work and if all you need is a static bar at the top that can host icons and a back button, then you can safely continue to use ActionBar
.
To use Toolbar
as an ActionBar
, first ensure the AppCompat-v7 support library is added to your application build.gradle (Module:app)
file
Second, let's disable the theme-provided ActionBar
. The easiest way is to have your theme extend from Theme.AppCompat.NoActionBar
(or the light variant) within the res/styles.xml
file
Now lets talk about the color scheme for our project, as you can see from the image below, there are attributes which you can set to get a basic color scheme of your App done, right now we are just dealing we App bar so we would talk about colorPrimary
and colorPrimaryDark
. colorPrimary
as the name says is the primary color of your App and the App bar while with the colorPrimaryDark
you can set the color of the status bar to a certain color.
Next, you need to add a Toolbar
to your Activity
layout file. Below I place the Toolbar
at the top of a LinearLayout
like the standard ActionBar
Next, in your Activity
or Fragment
, set the Toolbar
to act as the ActionBar
by calling the setSupportActionBar(Toolbar)
method
Adding items to ActionBar or Toolbar
Menus are typically created in resource files using XML but they are stored in the res/menu
directory though they can also be created in code. To create a menu resource, use the <menu>
element.
The <item>
element defines each individual menu item and is enclosed in the <menu>
element. A basic menu item looks as follows
The most common <item>
attributes are the following
id
, this is the standard resource identifier;title
, this indicates the text to display;icon
, this is a draw-able resource;showAsAction
, this controls how the menu item is shown;enabled
, this is enabled by default.
The showAsAction
attribute controls how the menu item is shown. The options include the following:
ifRoom
, this menu item should be included in the Action Bar if there's enough space;withText
, this indicates that both the title and the icon should be shown;never
, this indicates that the menu item should never be included in the Action Bar;always
, this indicates that the menu item should be always included in the Action Bar.
First, we will add a string resource to the strings.xml
file for the menu title. Start by opening the /res/values/strings.xml
file and add the following <string>
element to the <resources>
element <string name='menu_email'>EMail</string>
Create a new file in the res/menu
directory (right click on res
- New
- Android resource directory
) and call it menu_main.xml
.
Open the menu_main.xml
file and add the following XML to define the menu
With the menu now created, we just have to override the onCreateOptionsMenu()
method in our activity to inflate the menu
Add the following method to the application to see a Toast
when the EMail
menu is selected
If you want to show icon in overflow menu use following snippet
Creating sub menus
Sub menus are created and accessed in almost exactly the same manner as other menu elements and can be placed in any of the provided menus, although they cannot be placed within other sub menus. To define a sub menu, include a <menu>
element within an <item>
element.
Here is the XML form this recipe with two sub menu items added
Grouping menu items
Another menu feature that Android supports is grouping menu items. Android provides several methods for groups, including the following
setGroupVisible()
show or hide all items;setGroupEnabled()
enable or disable all items;setGroupCheckable()
set the checkable behavior.
Android will keep all grouped items with showAsAction='ifRoom'
together. This means all items in the group with showAsAction='ifRoom'
will be in the Action Bar or all items will be in the overflow.
To create a group, add the <item>
menu elements to a <group>
element. Here is an example using the menu XML from this recipe with two additional items in a group
Custom title
A Toolbar
is just a decorated ViewGroup
and as a result, the title contained within can be completely customized by embedding a view within the Toolbar
such as:
This means that you can style the TextView
like any other. You can access the TextView
inside your activity with:
Note that you must hide the default title using setDisplayShowTitleEnabled
. This results in:
How to change color of menu in Toolbar
How to add back button to Toolbar
Android context menu example
First, define main activity layout
Second, describe context menu items
Third, define events and action in MainActivity
class
onCreateContextMenu
called when a context menu for the view is about to be shown. Unlike onCreateOptionsMenu
, this will be called every time the context menu is about to be shown and should be populated for the view (or item inside the view for AdapterView
subclasses, this can be found in the menuInfo
).
onContextItemSelected
hook is called whenever an item in a context menu is selected. The default implementation simply returns false
to have the normal processing happen. You can use this method for any items for which you would like to do processing without those other facilities.
Toolbar example in Kotlin
Following is MainActivity.kt file.
Following is activity_main.xml file.
Following is toolbar_menu.xml file.
Result
Popup menu with icons example in Kotlin
Following is MainActivity.kt file.
Following is activity_main.xml file.
Following is popup_menu.xml file.
Toolbat with title and icons
Toolbar
File MainActivity.kt
File activity_main.xml
File toolbar.xml
Build Menu Bar Apps Store
